SYSPLIT CEILING Split Systems

5,3-18 kW • R32 Indoor unit for installations hanged on the wall or ceiling suspended, even in a corner

DC fan motor
Flexible horizontal and vertical installation
Motorised louver for automatic air distribution
Equipped with Infrared remote controller

Size

SYSPLIT CEILING 18 LNS HP Q#323553

Frequency: 50 Hz

SYSPLIT CEILING has an easy and flexible installation. Thanks to the compact design, it can be installed hanged on the wall or ceiling suspended, even in a corner.

The improved shape of the impeller blades ensure low noise level.
The unit has an automatic distribution of the treated air in the vertical direction.

The unit is equipped with an Auto-restart function that, in the event of an electric power failure, allows it to restart with the same settings it had before the power loss.

The on/off and alarm contacts, as well as the network port for centralized and BMS gateway, allow a remote control of the split system.

‌

Certifications

Green Ventilation

Our very own environmental performance benchmark guides you toward the most sustainable solutions within our portfolio. Only products which meet a set of easily verifiable minimum requirements in terms of energy efficiency, indoor air quality, safety, and the like are entitled to receive the Green Ventiulation™ label.

Tech specs

Technical Data

Article name

SYSPLIT CEILING 18 LNS HP Q

Article number

#323553

230V 1~ 50Hz
Performances
Cooling capacity	5.3	kW
Power consumption cooling	1.45	kW
Heating capacity	5.6	kW
Power consumption heating	1,500	W
General data
Frequency	50	Hz
Phases	1~
Voltage (nominal)	230	V
Sound data
Sound power level	59	dB(A)
Dimensions and weights
Weight	25.8	kg
